| CSRP-30 |
CSRP-30 |
CSRP-30 |
SS Rest Pad - Tapped - 5/16 Dia X 3/8 |
1 |
100777 |
CAD |
|
5/16 | 3/8 | 3/16 | #8-32 |
| CSRP-305 |
CSRP-30 |
CSRP-305 |
SS Rest Pad - Tapped - 5/16 Dia X 1/2 |
1 |
100788 |
CAD |
|
5/16 | 1/2 | 5/16 | #8-32 |
| CSRP-40 |
CSRP-30 |
CSRP-40 |
SS Rest Pad - Tapped - 3/8 Dia X 3/8 |
1 |
100796 |
CAD |
|
3/8 | 3/8 | 3/16 | #10-32 |
| CSRP-405 |
CSRP-30 |
CSRP-405 |
SS Rest Pad - Tapped - 3/8 Dia X 1/2 |
1 |
100813 |
CAD |
|
3/8 | 1/2 | 5/16 | #10-32 |
| CSRP-50 |
CSRP-30 |
CSRP-50 |
SS Rest Pad - Tapped - 1/2 Dia X 3/8 |
1 |
100827 |
CAD |
|
1/2 | 3/8 | 3/16 | #10-32 |
| CSRP-53 |
CSRP-30 |
CSRP-53 |
SS Rest Pad - Tapped - 1/2 Dia X 1/2 |
1 |
100837 |
CAD |
|
1/2 | 1/2 | 5/16 | #10-32 |
| CSRP-62 |
CSRP-30 |
CSRP-62 |
SS Rest Pad - Tapped - 5/8 Dia X 3/8 |
1 |
100843 |
CAD |
|
5/8 | 3/8 | 3/16 | 1/4-28 |
| CSRP-625 |
CSRP-30 |
CSRP-625 |
SS Rest Pad - Tapped - 5/8 Dia X 1/2 |
1 |
100854 |
CAD |
|
5/8 | 1/2 | 5/16 | 1/4-28 |
| CSRP-75 |
CSRP-30 |
CSRP-75 |
SS Rest Pad - Tapped - 3/4 Dia X 3/8 |
1 |
100872 |
CAD |
|
3/4 | 3/8 | 3/16 | 1/4-28 |
| CSRP-755 |
CSRP-30 |
CSRP-755 |
SS Rest Pad - Tapped - 3/4 Dia X 1/2 |
1 |
100892 |
CAD |
|
3/4 | 1/2 | 5/16 | 1/4-28 |
| CSRP-81 |
CSRP-30 |
CSRP-81 |
SS Rest Pad - Tapped - 1 Dia X 3/8 |
1 |
100925 |
CAD |
|
1 | 3/8 | 3/16 | 1/4-28 |
| CSRP-815 |
CSRP-30 |
CSRP-815 |
SS Rest Pad - Tapped - 1 Dia X 1/2 |
1 |
100940 |
CAD |
|
1 | 1/2 | 5/16 | 1/4-28 |
