MBBU-1012-S |
MBBU-1012-S |
MBBU-1012-S |
Base Design Swivot - 10 mm Dia X 10.5 mm - Super Fine |
1 |
101849 |
CAD |
|
10 | 10.5 | 6 | 1.5 | 28 | M4x0.7 | 3.5 | 7 | MBUB-070-S | SF | 2,585 |
MBBU-1012-S-T |
MBBU-1012-S |
MBBU-1012-S-T |
Base Design Swivot - 10 mm Dia X 10.5 mm - Super Fine - Tall |
1 |
101852 |
CAD |
|
10 | 10.5 | 6 | 3 | 28 | M4x0.7 | 3.5 | 7 | MBUB-070-S-T | SF | 2,585 |
MBBU-1025-S |
MBBU-1012-S |
MBBU-1025-S |
Base Design Swivot - 10 mm Dia X 23.5 mm - Super Fine |
1 |
101907 |
CAD |
|
10 | 23.5 | 6 | 1.5 | 28 | M4x0.7 | 9 | 7 | MBUB-070-S | SF | 2,585 |
MBBU-1025-S-T |
MBBU-1012-S |
MBBU-1025-S-T |
Base Design Swivot - 10 mm Dia X 23.5 mm - Super Fine - Tall |
1 |
101918 |
CAD |
|
10 | 23.5 | 6 | 3 | 28 | M4x0.7 | 9 | 7 | MBUB-070-S-T | SF | 2,585 |
MBBU-1316-S |
MBBU-1012-S |
MBBU-1316-S |
Base Design Swivot - 13 mm Dia X 14.5 mm - Extra Fine |
1 |
101968 |
CAD |
|
13 | 14.5 | 8.5 | 1.5 | 24 | M5x0.8 | 6.5 | 10 | MBUB-100-S | EF | 4,452 |
MBBU-1316-S-T |
MBBU-1012-S |
MBBU-1316-S-T |
Base Design Swivot - 13 mm Dia X 14.5 mm - Extra Fine - Tall |
1 |
101973 |
CAD |
|
13 | 14.5 | 8.5 | 3 | 24 | M5x0.8 | 6.5 | 10 | MBUB-100-S-T | EF | 4,452 |
MBBU-1325-S |
MBBU-1012-S |
MBBU-1325-S |
Base Design Swivot - 13 mm Dia X 23.5 mm - Extra Fine |
1 |
102039 |
CAD |
|
13 | 23.5 | 8.5 | 1.5 | 24 | M5x0.8 | 9 | 10 | MBUB-100-S | EF | 4,452 |
MBBU-1325-S-T |
MBBU-1012-S |
MBBU-1325-S-T |
Base Design Swivot - 13 mm Dia X 23.5 mm - Extra Fine - Tall |
1 |
102041 |
CAD |
|
13 | 23.5 | 8.5 | 3 | 24 | M5x0.8 | 9 | 10 | MBUB-100-S-T | EF | 4,452 |
MBBU-1722-S |
MBBU-1012-S |
MBBU-1722-S |
Base Design Swivot - 17 mm Dia X 18 mm - Extra Fine |
1 |
102112 |
CAD |
|
17 | 18 | 10 | 4 | 42 | M6x1.0 | 7.5 | 13 | MBUB-130-S | EF | 6,170 |
MBBU-1722-S-T |
MBBU-1012-S |
MBBU-1722-S-T |
Base Design Swivot - 17 mm Dia X 18 mm - Extra Fine - Tall |
1 |
102115 |
CAD |
|
17 | 18 | 10 | 6 | 42 | M6x1.0 | 7.5 | 13 | MBUB-130-S-T | EF | 6,170 |
MBBU-1924-S |
MBBU-1012-S |
MBBU-1924-S |
Base Design Swivot - 19 mm Dia X 20 mm - Fine |
1 |
102180 |
CAD |
|
19 | 20 | 12 | 4 | 45 | M8x1.25 | 8.5 | 15 | MBUB-150-S | Fine | 8,688 |
MBBU-1924-S-T |
MBBU-1012-S |
MBBU-1924-S-T |
Base Design Swivot - 19 mm Dia X 20 mm - Fine - Tall |
1 |
102183 |
CAD |
|
19 | 20 | 12 | 6 | 45 | M8x1.25 | 8.5 | 15 | MBUB-150-S-T | Fine | 8,688 |
MBBU-2428-S |
MBBU-1012-S |
MBBU-2428-S |
Base Design Swivot - 24 mm Dia X 20 mm - Fine |
1 |
101862 |
CAD |
|
24 | 24 | 16 | 4 | 40 | M10x1.5 | 9 | 20 | MBUB-200-S | Fine | 13,117 |
