MTBU-10025-S |
MTBU-10025-S |
MTBU-10025-S |
Threaded Design Swivot - M10 X 25 mm - Super Fine |
1 |
101926 |
CAD |
|
M10x1.5 | 25 | 4 | 1.5 | 30 | 5 | 5 | MBUB-050-S | SF | — |
MTBU-10035-S |
MTBU-10025-S |
MTBU-10035-S |
Threaded Design Swivot - M10 X 35 mm - Super Fine |
1 |
102004 |
CAD |
|
M10x1.5 | 35 | 4 | 1.5 | 30 | 5 | 5 | MBUB-050-S | SF | — |
MTBU-10050-S |
MTBU-10025-S |
MTBU-10050-S |
Threaded Design Swivot - M10 X 50 mm - Super Fine |
1 |
102047 |
CAD |
|
M10x1.5 | 50 | 4 | 1.5 | 30 | 5 | 5 | MBUB-050-S | SF | — |
MTBU-12025-S |
MTBU-10025-S |
MTBU-12025-S |
Threaded Design Swivot - M12 X 25 mm - Super Fine |
1 |
102141 |
CAD |
|
M12x1.75 | 25 | 6 | 1.5 | 28 | 6 | 7 | MBUB-070-S | SF | 3,440 |
MTBU-12025-S-T |
MTBU-10025-S |
MTBU-12025-S-T |
Threaded Design Swivot - M12 X 25 mm - Super Fine - Tall |
1 |
102146 |
CAD |
|
M12x1.75 | 25 | 6 | 3 | 28 | 6 | 7 | MBUB-070-S-T | SF | 3,440 |
MTBU-12035-S |
MTBU-10025-S |
MTBU-12035-S |
Threaded Design Swivot - M12 X 35 mm - Super Fine |
1 |
102206 |
CAD |
|
M12x1.75 | 35 | 6 | 1.5 | 28 | 6 | 7 | MBUB-070-S | SF | 3,440 |
MTBU-12035-S-T |
MTBU-10025-S |
MTBU-12035-S-T |
Threaded Design Swivot - M12 X 35 mm - Super Fine - Tall |
1 |
102208 |
CAD |
|
M12x1.75 | 35 | 6 | 3 | 28 | 6 | 7 | MBUB-070-S-T | SF | 3,440 |
MTBU-12050-S |
MTBU-10025-S |
MTBU-12050-S |
Threaded Design Swivot - M12 X 50 mm - Super Fine |
1 |
102276 |
CAD |
|
M12x1.75 | 50 | 6 | 1.5 | 28 | 6 | 7 | MBUB-070-S | SF | 3,440 |
MTBU-12050-S-T |
MTBU-10025-S |
MTBU-12050-S-T |
Threaded Design Swivot - M12 X 50 mm - Super Fine - Tall |
1 |
102289 |
CAD |
|
M12x1.75 | 50 | 6 | 3 | 28 | 6 | 7 | MBUB-070-S-T | SF | 3,440 |
MTBU-16025-S |
MTBU-10025-S |
MTBU-16025-S |
Threaded Design Swivot - M16 X 25 mm - Extra Fine |
1 |
102385 |
CAD |
|
M16x2.0 | 25 | 8.5 | 1.5 | 24 | 8 | 10 | MBUB-100-S | EF | 5,190 |
MTBU-16025-S-T |
MTBU-10025-S |
MTBU-16025-S-T |
Threaded Design Swivot - M16 X 25 mm - Extra Fine - Tall |
1 |
102420 |
CAD |
|
M16x2.0 | 25 | 8.5 | 3 | 24 | 8 | 10 | MBUB-100-S-T | EF | 5,190 |
MTBU-16035-S |
MTBU-10025-S |
MTBU-16035-S |
Threaded Design Swivot - M16 X 35 mm - Extra Fine |
1 |
102490 |
CAD |
|
M16x2.0 | 35 | 8.5 | 1.5 | 24 | 8 | 10 | MBUB-100-S | EF | 5,190 |
MTBU-16035-S-T |
MTBU-10025-S |
MTBU-16035-S-T |
Threaded Design Swivot - M16 X 35 mm - Extra Fine - Tall |
1 |
102510 |
CAD |
|
M16x2.0 | 35 | 8.5 | 3 | 24 | 8 | 10 | MBUB-100-S-T | EF | 5,190 |
MTBU-16050-S |
MTBU-10025-S |
MTBU-16050-S |
Threaded Design Swivot - M16 X 50 mm - Extra Fine |
1 |
102604 |
CAD |
|
M16x2.0 | 50 | 8.5 | 1.5 | 24 | 8 | 10 | MBUB-100-S | EF | 5,190 |
MTBU-16050-S-T |
MTBU-10025-S |
MTBU-16050-S-T |
Threaded Design Swivot - M16 X 50 mm - Extra Fine - Tall |
1 |
102610 |
CAD |
|
M16x2.0 | 50 | 8.5 | 3 | 24 | 8 | 10 | MBUB-100-S-T | EF | 5,190 |
MTBU-20030-S |
MTBU-10025-S |
MTBU-20030-S |
Threaded Design Swivot - M20 X 30 mm - Extra Fine |
1 |
102674 |
CAD |
|
M20x2.5 | 30 | 10 | 4 | 42 | 10 | 13 | MBUB-130-S | EF | 8,379 |
MTBU-20030-S-T |
MTBU-10025-S |
MTBU-20030-S-T |
Threaded Design Swivot - M20 X 30 mm - Extra Fine - Tall |
1 |
102682 |
CAD |
|
M20x2.5 | 30 | 10 | 6 | 42 | 10 | 13 | MBUB-130-S-T | EF | 8,379 |
MTBU-20050-S |
MTBU-10025-S |
MTBU-20050-S |
Threaded Design Swivot - M20 X 50 mm - Extra Fine |
1 |
102739 |
CAD |
|
M20x2.5 | 50 | 10 | 4 | 42 | 10 | 13 | MBUB-130-S | EF | 8,379 |
MTBU-20050-S-T |
MTBU-10025-S |
MTBU-20050-S-T |
Threaded Design Swivot - M20 X 50 mm - Extra Fine - Tall |
1 |
102746 |
CAD |
|
M20x2.5 | 50 | 10 | 6 | 42 | 10 | 13 | MBUB-130-S-T | EF | 8,379 |
MTBU-20070-S |
MTBU-10025-S |
MTBU-20070-S |
Threaded Design Swivot - M20 X 70 mm - Extra Fine |
1 |
102886 |
CAD |
|
M20x2.5 | 70 | 10 | 4 | 42 | 10 | 13 | MBUB-130-S | EF | 8,379 |
MTBU-20070-S-T |
MTBU-10025-S |
MTBU-20070-S-T |
Threaded Design Swivot - M20 X 70 mm - Extra Fine - Tall |
1 |
102916 |
CAD |
|
M20x2.5 | 70 | 10 | 6 | 42 | 10 | 13 | MBUB-130-S-T | EF | 8,379 |
MTBU-24040-S |
MTBU-10025-S |
MTBU-24040-S |
Threaded Design Swivot - M24 X 40 mm - Fine |
1 |
103039 |
CAD |
|
M24x3.0 | 40 | 12 | 4 | 45 | 10 | 15 | MBUB-150-S | Fine | 12,233 |
MTBU-24040-S-T |
MTBU-10025-S |
MTBU-24040-S-T |
Threaded Design Swivot - M24 X 40 mm - Fine - Tall |
1 |
103055 |
CAD |
|
M24x3.0 | 40 | 12 | 6 | 45 | 10 | 15 | MBUB-150-S-T | Fine | 12,233 |
MTBU-24080-S |
MTBU-10025-S |
MTBU-24080-S |
Threaded Design Swivot - M24 X 80 mm - Fine |
1 |
103162 |
CAD |
|
M24x3.0 | 80 | 12 | 4 | 45 | 10 | 15 | MBUB-150-S | Fine | 12,233 |
MTBU-24080-S-T |
MTBU-10025-S |
MTBU-24080-S-T |
Threaded Design Swivot - M24 X 80 mm - Fine - Tall |
1 |
103166 |
CAD |
|
M24x3.0 | 80 | 12 | 6 | 45 | 10 | 15 | MBUB-150-S-T | Fine | 12,233 |
