MTBU-12025-F |
MTBU-10025-F |
MTBU-12025-F |
Threaded Design Swivot - M12 X 25 mm - Flat |
1 |
102075 |
CAD |
|
M12x1.75 | 25 | 6 | 1.5 | 28 | 6 | 7 | MBUB-070-F | 3,440 |
MTBU-12025-F-T |
MTBU-10025-F |
MTBU-12025-F-T |
Threaded Design Swivot - M12 X 25 mm - Flat - Tall |
1 |
102104 |
CAD |
|
M12x1.75 | 25 | 6 | 3 | 28 | 6 | 7 | MBUB-070-F-T | 3,440 |
MTBU-12035-F |
MTBU-10025-F |
MTBU-12035-F |
Threaded Design Swivot - M12 X 35 mm - Flat |
1 |
102160 |
CAD |
|
M12x1.75 | 35 | 6 | 1.5 | 28 | 6 | 7 | MBUB-070-F | 3,440 |
MTBU-12035-F-T |
MTBU-10025-F |
MTBU-12035-F-T |
Threaded Design Swivot - M12 X 35 mm - Flat - Tall |
1 |
102163 |
CAD |
|
M12x1.75 | 35 | 6 | 3 | 28 | 6 | 7 | MBUB-070-F-T | 3,440 |
MTBU-12050-F |
MTBU-10025-F |
MTBU-12050-F |
Threaded Design Swivot - M12 X 50 mm - Flat |
1 |
102237 |
CAD |
|
M12x1.75 | 50 | 6 | 1.5 | 28 | 6 | 7 | MBUB-070-F | 3,440 |
MTBU-12050-F-T |
MTBU-10025-F |
MTBU-12050-F-T |
Threaded Design Swivot - M12 X 50 mm - Flat - Tall |
1 |
102241 |
CAD |
|
M12x1.75 | 50 | 6 | 3 | 28 | 6 | 7 | MBUB-070-F-T | 3,440 |
MTBU-16025-F |
MTBU-10025-F |
MTBU-16025-F |
Threaded Design Swivot - M16 X 25 mm - Flat |
1 |
102311 |
CAD |
|
M16x2.0 | 25 | 8.5 | 1.5 | 24 | 8 | 10 | MBUB-100-F | 5,190 |
MTBU-16025-F-T |
MTBU-10025-F |
MTBU-16025-F-T |
Threaded Design Swivot - M16 X 25 mm - Flat - Tall |
1 |
102319 |
CAD |
|
M16x2.0 | 25 | 8.5 | 3 | 24 | 8 | 10 | MBUB-100-F-T | 5,190 |
MTBU-16035-F |
MTBU-10025-F |
MTBU-16035-F |
Threaded Design Swivot - M16 X 35 mm - Flat |
1 |
102448 |
CAD |
|
M16x2.0 | 35 | 8.5 | 1.5 | 24 | 8 | 10 | MBUB-100-F | 5,190 |
MTBU-16035-F-T |
MTBU-10025-F |
MTBU-16035-F-T |
Threaded Design Swivot - M16 X 25 mm - Flat - Tall |
1 |
102452 |
CAD |
|
M16x2.0 | 35 | 8.5 | 3 | 24 | 8 | 10 | MBUB-100-F-T | 5,190 |
MTBU-16050-F |
MTBU-10025-F |
MTBU-16050-F |
Threaded Design Swivot - M16 X 50 mm - Flat |
1 |
102543 |
CAD |
|
M16x2.0 | 50 | 8.5 | 1.5 | 24 | 8 | 10 | MBUB-100-F | 5,190 |
MTBU-16050-F-T |
MTBU-10025-F |
MTBU-16050-F-T |
Threaded Design Swivot - M16 X 50 mm - Flat - Tall |
1 |
102546 |
CAD |
|
M16x2.0 | 50 | 8.5 | 3 | 24 | 8 | 10 | MBUB-100-F-T | 5,190 |
MTBU-20030-F |
MTBU-10025-F |
MTBU-20030-F |
Threaded Design Swivot - M20 X 30 mm - Flat |
1 |
102629 |
CAD |
|
M20x2.5 | 30 | 10 | 4 | 42 | 10 | 13 | MBUB-130-F | 8,379 |
MTBU-20030-F-T |
MTBU-10025-F |
MTBU-20030-F-T |
Threaded Design Swivot - M20 X 30 mm - Flat - Tall |
1 |
102631 |
CAD |
|
M20x2.5 | 30 | 10 | 6 | 42 | 10 | 13 | MBUB-130-F-T | 8,379 |
MTBU-20050-F |
MTBU-10025-F |
MTBU-20050-F |
Threaded Design Swivot - M20 X 50 mm - Flat |
1 |
102703 |
CAD |
|
M20x2.5 | 50 | 10 | 4 | 42 | 10 | 13 | MBUB-130-F | 8,379 |
MTBU-20050-F-T |
MTBU-10025-F |
MTBU-20050-F-T |
Threaded Design Swivot - M20 X 50 mm - Flat - Tall |
1 |
102707 |
CAD |
|
M20x2.5 | 50 | 10 | 6 | 42 | 10 | 13 | MBUB-130-F-T | 8,379 |
MTBU-20070-F |
MTBU-10025-F |
MTBU-20070-F |
Threaded Design Swivot - M20 X 70 mm - Flat |
1 |
102791 |
CAD |
|
M20x2.5 | 70 | 10 | 4 | 42 | 10 | 13 | MBUB-130-F | 8,379 |
MTBU-20070-F-T |
MTBU-10025-F |
MTBU-20070-F-T |
Threaded Design Swivot - M20 X 70 mm - Flat - Tall |
1 |
102811 |
CAD |
|
M20x2.5 | 70 | 10 | 6 | 42 | 10 | 13 | MBUB-130-F-T | 8,379 |
MTBU-24040-F |
MTBU-10025-F |
MTBU-24040-F |
Threaded Design Swivot - M24 X 40 mm - Flat |
1 |
102955 |
CAD |
|
M24x3.0 | 40 | 12 | 4 | 45 | 10 | 15 | MBUB-150-F | 12,233 |
MTBU-24040-F-T |
MTBU-10025-F |
MTBU-24040-F-T |
Threaded Design Swivot - M24 X 40 mm - Flat - Tall |
1 |
102962 |
CAD |
|
M24x3.0 | 40 | 12 | 6 | 45 | 10 | 15 | MBUB-150-F-T | 12,233 |
MTBU-24080-F |
MTBU-10025-F |
MTBU-24080-F |
Threaded Design Swivot - M24 X 80 mm - Flat |
1 |
103103 |
CAD |
|
M24x3.0 | 80 | 12 | 4 | 45 | 10 | 15 | MBUB-150-F | 12,233 |
MTBU-24080-F-T |
MTBU-10025-F |
MTBU-24080-F-T |
Threaded Design Swivot - M24 X 80 mm - Flat - Tall |
1 |
103109 |
CAD |
|
M24x3.0 | 80 | 12 | 6 | 45 | 10 | 15 | MBUB-150-F-T | 12,233 |
