BBU-100-FC |
BBU-100-FC |
BBU-100-FC |
Base Design Swivot - 3/8 Dia X 5/16 - SS Cone |
1 |
109189 |
CAD |
|
3/8 | 5/16 | .236 | .063 | 28 | #4-40 | 1/4 | 3/16 | BUB-187-FC | 1,835 |
BBU-105-FC |
BBU-100-FC |
BBU-105-FC |
Base Design Swivot - 3/8 Dia X 7/16 - SS Cone |
1 |
101217 |
CAD |
|
3/8 | 7/16 | .236 | .063 | 28 | #4-40 | 5/16 | 3/16 | BUB-187-FC | 1,835 |
BBU-107-FC |
BBU-100-FC |
BBU-107-FC |
Base Design Swivot - 3/8 Dia X 11/16 - SS Cone |
1 |
101269 |
CAD |
|
3/8 | 11/16 | .236 | .063 | 28 | #4-40 | 5/16 | 3/16 | BUB-187-FC | 1,835 |
BBU-200-FC |
BBU-100-FC |
BBU-200-FC |
Base Design Swivot - 7/16 Dia X 3/8 - SS Cone |
1 |
101373 |
CAD |
|
7/16 | 3/8 | .315 | .094 | 28 | #8-32 | 5/32 | 9/32 | BUB-200-FC | 3,339 |
BBU-201-FC |
BBU-100-FC |
BBU-201-FC |
Base Design Swivot - 7/16 Dia X 15/16 - SS Cone |
1 |
101428 |
CAD |
|
7/16 | 15/16 | .315 | .094 | 28 | #8-32 | 1/2 | 9/32 | BUB-200-FC | 3,339 |
BBU-300-FC |
BBU-100-FC |
BBU-300-FC |
Base Design Swivot - 1/2 Dia X 1/2 - SS Cone |
1 |
101484 |
CAD |
|
1/2 | 1/2 | .433 | .125 | 28 | #10-32 | 5/32 | 3/8 | BUB-300-FC | 4,697 |
BBU-301-FC |
BBU-100-FC |
BBU-301-FC |
Base Design Swivot - 1/2 Dia X 1 - SS Cone |
1 |
101554 |
CAD |
|
1/2 | 1 | .433 | .125 | 28 | #10-32 | 5/8 | 3/8 | BUB-300-FC | 4,697 |
BBU-500-FC |
BBU-100-FC |
BBU-500-FC |
Base Design Swivot - 5/8 Dia X 3/4 - SS Cone |
1 |
101606 |
CAD |
|
5/8 | 3/4 | .551 | .125 | 28 | 1/4-28 | 1/4 | 1/2 | BUB-500-FC | 5,849 |
BBU-600-FC |
BBU-100-FC |
BBU-600-FC |
Base Design Swivot - 13/16 Dia X 7/8 - SS Cone |
1 |
101683 |
CAD |
|
13/16 | 7/8 | .748 | .156 | 32 | 5/16-24 | 11/32 | 5/8 | BUB-600-FC | 10,925 |
BBU-700-FC |
BBU-100-FC |
BBU-700-FC |
Base Design Swivot - 15/16 Dia X 7/8 - SS Cone |
1 |
101756 |
CAD |
|
15/16 | 7/8 | .827 | .156 | 32 | 3/8-24 | 9/32 | 3/4 | BUB-700-FC | 13,325 |
