TBU-0370-FC |
TBU-0230-FC |
TBU-0370-FC |
Threaded Design Swivot - 3/8-16 X 1/2 - SS Cone |
1 |
101854 |
CAD |
|
3/8-16 | 1/2 | .236 | .063 | 28 | 3/16 | 3/16 | BUB-187-FC | 1,763 |
TBU-0375-FC |
TBU-0230-FC |
TBU-0375-FC |
Threaded Design Swivot - 3/8-16 X 1 - SS Cone |
1 |
101933 |
CAD |
|
3/8-16 | 1 | .236 | .063 | 28 | 3/16 | 3/16 | BUB-187-FC | 1,763 |
TBU-0375X2-FC |
TBU-0230-FC |
TBU-0375X2-FC |
Threaded Design Swivot - 3/8-16 X 2 - SS Cone |
1 |
102010 |
CAD |
|
3/8-16 | 2 | .236 | .063 | 28 | 3/16 | 3/16 | BUB-187-FC | 1,763 |
TBU-0375X3-FC |
TBU-0230-FC |
TBU-0375X3-FC |
Threaded Design Swivot - 3/8-16 X 3 - SS Cone |
1 |
102083 |
CAD |
|
3/8-16 | 3 | .236 | .063 | 28 | 3/16 | 3/16 | BUB-187-FC | 1,763 |
TBU-0230-FC |
TBU-0230-FC |
TBU-0230-FC |
Threaded Design Swivot - 3/8-24 X 1/2 - SS Cone |
1 |
103183 |
CAD |
|
3/8-24 | 1/2 | .236 | .063 | 28 | 3/16 | 3/16 | BUB-187-FC | 1,763 |
TBU-0231-FC |
TBU-0230-FC |
TBU-0231-FC |
Threaded Design Swivot - 3/8-24 X 1 - SS Cone |
1 |
103243 |
CAD |
|
3/8-24 | 1 | .236 | .063 | 28 | 3/16 | 3/16 | BUB-187-FC | 1,763 |
TBU-0231X2-FC |
TBU-0230-FC |
TBU-0231X2-FC |
Threaded Design Swivot - 3/8-24 X 2 - SS Cone |
1 |
103314 |
CAD |
|
3/8-24 | 2 | .236 | .063 | 28 | 3/16 | 3/16 | BUB-187-FC | 1,763 |
TBU-0231X3-FC |
TBU-0230-FC |
TBU-0231X3-FC |
Threaded Design Swivot - 3/8-24 X 3 - SS Cone |
1 |
103341 |
CAD |
|
3/8-24 | 3 | .236 | .063 | 28 | 3/16 | 3/16 | BUB-187-FC | 1,763 |
TBU-0513-FC |
TBU-0230-FC |
TBU-0513-FC |
Threaded Design Swivot - 1/2-13 X 3/4 - SS Cone |
1 |
102861 |
CAD |
|
1/2-13 | 3/4 | .315 | .094 | 28 | 1/4 | 9/32 | BUB-200-FC | 4,527 |
TBU-0510-FC |
TBU-0230-FC |
TBU-0510-FC |
Threaded Design Swivot - 1/2-13 X 1 - SS Cone |
1 |
102592 |
CAD |
|
1/2-13 | 1 | .315 | .094 | 28 | 1/4 | 9/32 | BUB-200-FC | 4,527 |
TBU-0510X2-FC |
TBU-0230-FC |
TBU-0510X2-FC |
Threaded Design Swivot - 1/2-13 X 2 - SS Cone |
1 |
102670 |
CAD |
|
1/2-13 | 2 | .315 | .094 | 28 | 1/4 | 9/32 | BUB-200-FC | 4,527 |
TBU-0510X3-FC |
TBU-0230-FC |
TBU-0510X3-FC |
Threaded Design Swivot - 1/2-13 X 3 - SS Cone |
1 |
102756 |
CAD |
|
1/2-13 | 3 | .315 | .094 | 28 | 1/4 | 9/32 | BUB-200-FC | 4,527 |
TBU-0503-FC |
TBU-0230-FC |
TBU-0503-FC |
Threaded Design Swivot - 1/2-20 X 3/4 - SS Cone |
1 |
102491 |
CAD |
|
1/2-20 | 3/4 | .315 | .094 | 28 | 1/4 | 9/32 | BUB-200-FC | 4,527 |
TBU-0500-FC |
TBU-0230-FC |
TBU-0500-FC |
Threaded Design Swivot - 1/2-20 X 1 - SS Cone |
1 |
102194 |
CAD |
|
1/2-20 | 1 | .315 | .094 | 28 | 1/4 | 9/32 | BUB-200-FC | 4,527 |
TBU-0500X2-FC |
TBU-0230-FC |
TBU-0500X2-FC |
Threaded Design Swivot - 1/2-20 X 2 - SS Cone |
1 |
102287 |
CAD |
|
1/2-20 | 2 | .315 | .094 | 28 | 1/4 | 9/32 | BUB-200-FC | 4,527 |
TBU-0500X3-FC |
TBU-0230-FC |
TBU-0500X3-FC |
Threaded Design Swivot - 1/2-20 X 3 - SS Cone |
1 |
102365 |
CAD |
|
1/2-20 | 3 | .315 | .094 | 28 | 1/4 | 9/32 | BUB-200-FC | 4,527 |
TBU-0625-FC |
TBU-0230-FC |
TBU-0625-FC |
Threaded Design Swivot - 5/8-11 X 1 - SS Cone |
1 |
103252 |
CAD |
|
5/8-11 | 1 | .433 | .125 | 28 | 5/16 | 3/8 | BUB-300-FC | 6,131 |
TBU-0625X2-FC |
TBU-0230-FC |
TBU-0625X2-FC |
Threaded Design Swivot - 5/8-11 X 2 - SS Cone |
1 |
103377 |
CAD |
|
5/8-11 | 2 | .433 | .125 | 28 | 5/16 | 3/8 | BUB-300-FC | 6,131 |
TBU-0625X3-FC |
TBU-0230-FC |
TBU-0625X3-FC |
Threaded Design Swivot - 5/8-11 X 3 - SS Cone |
1 |
101945 |
CAD |
|
5/8-11 | 3 | .433 | .125 | 28 | 5/16 | 3/8 | BUB-300-FC | 6,131 |
TBU-0620-FC |
TBU-0230-FC |
TBU-0620-FC |
Threaded Design Swivot - 5/8-18 X 1 - SS Cone |
1 |
102935 |
CAD |
|
5/8-18 | 1 | .433 | .125 | 28 | 5/16 | 3/8 | BUB-300-FC | 6,131 |
TBU-0620X2-FC |
TBU-0230-FC |
TBU-0620X2-FC |
Threaded Design Swivot - 5/8-18 X 2 - SS Cone |
1 |
103011 |
CAD |
|
5/8-18 | 2 | .433 | .125 | 28 | 5/16 | 3/8 | BUB-300-FC | 6,131 |
TBU-0620X3-FC |
TBU-0230-FC |
TBU-0620X3-FC |
Threaded Design Swivot - 5/8-18 X 3 - SS Cone |
1 |
103132 |
CAD |
|
5/8-18 | 3 | .433 | .125 | 28 | 5/16 | 3/8 | BUB-300-FC | 6,131 |
TBU-0755-FC |
TBU-0230-FC |
TBU-0755-FC |
Threaded Design Swivot - 3/4-10 X 1 - SS Cone |
1 |
102406 |
CAD |
|
3/4-10 | 1 | .551 | .125 | 28 | 3/8 | 1/2 | BUB-500-FC | 8,150 |
TBU-0755X2-FC |
TBU-0230-FC |
TBU-0755X2-FC |
Threaded Design Swivot - 3/4-10 X 2 - SS Cone |
1 |
102502 |
CAD |
|
3/4-10 | 2 | .551 | .125 | 28 | 3/8 | 1/2 | BUB-500-FC | 8,150 |
TBU-0755X3-FC |
TBU-0230-FC |
TBU-0755X3-FC |
Threaded Design Swivot - 3/4-10 X 3 - SS Cone |
1 |
102640 |
CAD |
|
3/4-10 | 3 | .551 | .125 | 28 | 3/8 | 1/2 | BUB-500-FC | 8,150 |
TBU-0750-FC |
TBU-0230-FC |
TBU-0750-FC |
Threaded Design Swivot - 3/4-16 X 1 - SS Cone |
1 |
102049 |
CAD |
|
3/4-16 | 1 | .551 | .125 | 28 | 3/8 | 1/2 | BUB-500-FC | 8,150 |
TBU-0750X2-FC |
TBU-0230-FC |
TBU-0750X2-FC |
Threaded Design Swivot - 3/4-16 X 2 - SS Cone |
1 |
102140 |
CAD |
|
3/4-16 | 2 | .551 | .125 | 28 | 3/8 | 1/2 | BUB-500-FC | 8,150 |
TBU-0750X3-FC |
TBU-0230-FC |
TBU-0750X3-FC |
Threaded Design Swivot - 3/4-16 X 3 - SS Cone |
1 |
102270 |
CAD |
|
3/4-16 | 3 | .551 | .125 | 28 | 3/8 | 1/2 | BUB-500-FC | 8,150 |
TBU-1108-FC |
TBU-0230-FC |
TBU-1108-FC |
Threaded Design Swivot - 1-8 X 1 - SS Cone |
1 |
102749 |
CAD |
|
1-8 | 1 | .748 | .156 | 32 | 3/8 | 5/8 | BUB-600-FC | 14,757 |
TBU-1108X2-FC |
TBU-0230-FC |
TBU-1108X2-FC |
Threaded Design Swivot - 1-8 X 2 - SS Cone |
1 |
102892 |
CAD |
|
1-8 | 2 | .748 | .156 | 32 | 3/8 | 5/8 | BUB-600-FC | 14,757 |
TBU-1108X3-FC |
TBU-0230-FC |
TBU-1108X3-FC |
Threaded Design Swivot - 1-8 X 3 - SS Cone |
1 |
103018 |
CAD |
|
1-8 | 3 | .748 | .156 | 32 | 3/8 | 5/8 | BUB-600-FC | 14,757 |
TBU-1114-FC |
TBU-0230-FC |
TBU-1114-FC |
Threaded Design Swivot - 1-14 X 1 - SS Cone |
1 |
103189 |
CAD |
|
1-14 | 1 | .827 | .156 | 32 | 3/8 | 3/4 | BUB-700-FC | 17,210 |
TBU-1114X2-FC |
TBU-0230-FC |
TBU-1114X2-FC |
Threaded Design Swivot - 1-14 X 2 - SS Cone |
1 |
103291 |
CAD |
|
1-14 | 2 | .827 | .156 | 32 | 3/8 | 3/4 | BUB-700-FC | 17,210 |
TBU-1114X3-FC |
TBU-0230-FC |
TBU-1114X3-FC |
Threaded Design Swivot - 1-14 X 3 - SS Cone |
1 |
103427 |
CAD |
|
1-14 | 3 | .827 | .156 | 32 | 3/8 | 3/4 | BUB-700-FC | 17,210 |
