BUH-0124-DC |
BUH-0124-DC |
BUH-0124-DC |
Hex Design Swivot - 10-24 X 1/2 - Delrin Cone |
1 |
101528 |
CAD |
|
3/8 | 1/4 | 1/2 | .236 | .063 | #10-24 | 28 | — | 3/16 | BUB-187-DC |
BUH-0124X1-DC |
BUH-0124-DC |
BUH-0124X1-DC |
Hex Design Swivot - 10-24 X 1 - Delrin Cone |
1 |
101593 |
CAD |
|
3/8 | 1/4 | 1 | .236 | .063 | #10-24 | 28 | — | 3/16 | BUB-187-DC |
BUH-0132-DC |
BUH-0124-DC |
BUH-0132-DC |
Hex Design Swivot - 10-32 X 1/2 - Delrin Cone |
1 |
101644 |
CAD |
|
3/8 | 1/4 | 1/2 | .236 | .063 | #10-32 | 28 | — | 3/16 | BUB-187-DC |
BUH-0132X1-DC |
BUH-0124-DC |
BUH-0132X1-DC |
Hex Design Swivot - 10-32 X 1 - Delrin Cone |
1 |
101700 |
CAD |
|
3/8 | 1/4 | 1 | .236 | .063 | #10-32 | 28 | — | 3/16 | BUB-187-DC |
BUH-0250-DC |
BUH-0124-DC |
BUH-0250-DC |
Hex Design Swivot - 1/4-20 X 1/2 - Delrin Cone |
1 |
102224 |
CAD |
|
7/16 | 5/16 | 1/2 | .315 | .094 | 1/4-20 | 28 | — | 9/32 | BUB-200-DC |
BUH-0251-DC |
BUH-0124-DC |
BUH-0251-DC |
Hex Design Swivot - 1/4-20 X 1 - Delrin Cone |
1 |
102272 |
CAD |
|
7/16 | 5/16 | 1 | .315 | .094 | 1/4-20 | 28 | — | 9/32 | BUB-200-DC |
BUH-0251X1.5-DC |
BUH-0124-DC |
BUH-0251X1.5-DC |
Hex Design Swivot - 1/4-20 X 1-1/2 - Delrin Cone |
1 |
102351 |
CAD |
|
7/16 | 5/16 | 1-1/2 | .315 | .094 | 1/4-20 | 28 | — | 9/32 | BUB-200-DC |
BUH-0280-DC |
BUH-0124-DC |
BUH-0280-DC |
Hex Design Swivot - 1/4-28 X 1/2 - Delrin Cone |
1 |
102415 |
CAD |
|
7/16 | 5/16 | 1/2 | .315 | .094 | 1/4-28 | 28 | — | 9/32 | BUB-200-DC |
BUH-0281-DC |
BUH-0124-DC |
BUH-0281-DC |
Hex Design Swivot - 1/4-28 X 1 - Delrin Cone |
1 |
102482 |
CAD |
|
7/16 | 5/16 | 1 | .315 | .094 | 1/4-28 | 28 | — | 9/32 | BUB-200-DC |
BUH-0281X1.5-DC |
BUH-0124-DC |
BUH-0281X1.5-DC |
Hex Design Swivot - 1/4-28 X 1-1/2 - Delrin Cone |
1 |
102540 |
CAD |
|
7/16 | 5/16 | 1-1/2 | .315 | .094 | 1/4-28 | 28 | — | 9/32 | BUB-200-DC |
BUH-0310-DC |
BUH-0124-DC |
BUH-0310-DC |
Hex Design Swivot - 5/16-18 X 1/2 - Delrin Cone |
1 |
102672 |
CAD |
|
1/2 | 3/8 | 1/2 | .433 | .125 | 5/16-18 | 28 | — | 3/8 | BUB-300-DC |
BUH-0312-DC |
BUH-0124-DC |
BUH-0312-DC |
Hex Design Swivot - 5/16-18 X 1 - Delrin Cone |
1 |
102821 |
CAD |
|
1/2 | 3/8 | 1 | .433 | .125 | 5/16-18 | 28 | — | 3/8 | BUB-300-DC |
BUH-0312X1.5-DC |
BUH-0124-DC |
BUH-0312X1.5-DC |
Hex Design Swivot - 5/16-18 X 1-1/2 - Delrin Cone |
1 |
102908 |
CAD |
|
1/2 | 3/8 | 1-1/2 | .433 | .125 | 5/16-18 | 28 | — | 3/8 | BUB-300-DC |
BUH-0320-DC |
BUH-0124-DC |
BUH-0320-DC |
Hex Design Swivot - 5/16-24 X 1/2 - Delrin Cone |
1 |
101670 |
CAD |
|
1/2 | 3/8 | 1/2 | .433 | .125 | 5/16-24 | 28 | — | 3/8 | BUB-300-DC |
BUH-0321-DC |
BUH-0124-DC |
BUH-0321-DC |
Hex Design Swivot - 5/16-24 X 1 - Delrin Cone |
1 |
101781 |
CAD |
|
1/2 | 3/8 | 1 | .433 | .125 | 5/16-24 | 28 | — | 3/8 | BUB-300-DC |
BUH-0321X1.5-DC |
BUH-0124-DC |
BUH-0321X1.5-DC |
Hex Design Swivot - 5/16-24 X 1-1/2 - Delrin Cone |
1 |
101895 |
CAD |
|
1/2 | 3/8 | 1-1/2 | .433 | .125 | 5/16-24 | 28 | — | 3/8 | BUB-300-DC |
BUH-0370-DC |
BUH-0124-DC |
BUH-0370-DC |
Hex Design Swivot - 3/8-16 X 1/2 - Delrin Cone |
1 |
101979 |
CAD |
|
5/8 | 1/2 | 1/2 | .551 | .125 | 3/8-16 | 28 | 1/8 | 1/2 | BUB-500-DC |
BUH-0375-DC |
BUH-0124-DC |
BUH-0375-DC |
Hex Design Swivot - 3/8-16 X 1 - Delrin Cone |
1 |
102087 |
CAD |
|
5/8 | 1/2 | 1 | .551 | .125 | 3/8-16 | 28 | 1/8 | 1/2 | BUB-500-DC |
BUH-0375X1.5-DC |
BUH-0124-DC |
BUH-0375X1.5-DC |
Hex Design Swivot - 3/8-16 X 1-1/2 - Delrin Cone |
1 |
102190 |
CAD |
|
5/8 | 1/2 | 1-1/2 | .551 | .125 | 3/8-16 | 28 | 1/8 | 1/2 | BUB-500-DC |
BUH-0230-DC |
BUH-0124-DC |
BUH-0230-DC |
Hex Design Swivot - 3/8-24 X 1/2 - Delrin Cone |
1 |
101786 |
CAD |
|
5/8 | 1/2 | 1/2 | .551 | .125 | 3/8-24 | 28 | 1/8 | 1/2 | BUB-500-DC |
BUH-0231-DC |
BUH-0124-DC |
BUH-0231-DC |
Hex Design Swivot - 3/8-24 X 1 - Delrin Cone |
1 |
101908 |
CAD |
|
5/8 | 1/2 | 1 | .551 | .125 | 3/8-24 | 28 | 1/8 | 1/2 | BUB-500-DC |
BUH-0231X1.5-DC |
BUH-0124-DC |
BUH-0231X1.5-DC |
Hex Design Swivot - 3/8-24 X 1-1/2 - Delrin Cone |
1 |
102008 |
CAD |
|
5/8 | 1/2 | 1-1/2 | .551 | .125 | 3/8-24 | 28 | 1/8 | 1/2 | BUB-500-DC |
BUH-0510-DC |
BUH-0124-DC |
BUH-0510-DC |
Hex Design Swivot - 1/2-13 X 1 - Delrin Cone |
1 |
102499 |
CAD |
|
13/16 | 5/8 | 1 | .748 | .156 | 1/2-13 | 32 | 3/16 | 5/8 | BUB-600-DC |
BUH-0515-DC |
BUH-0124-DC |
BUH-0515-DC |
Hex Design Swivot - 1/2-13 X 1-1/2 - Delrin Cone |
1 |
102622 |
CAD |
|
13/16 | 5/8 | 1-1/2 | .748 | .156 | 1/2-13 | 32 | 3/16 | 5/8 | BUB-600-DC |
BUH-0240-DC |
BUH-0124-DC |
BUH-0240-DC |
Hex Design Swivot - 1/2-20 X 1 - Delrin Cone |
1 |
102117 |
CAD |
|
13/16 | 5/8 | 1 | .748 | .156 | 1/2-20 | 32 | 3/16 | 5/8 | BUB-600-DC |
BUH-0500-DC |
BUH-0124-DC |
BUH-0500-DC |
Hex Design Swivot - 1/2-20 X 1-1/2 - Delrin Cone |
1 |
102375 |
CAD |
|
13/16 | 5/8 | 1-1/2 | .748 | .156 | 1/2-20 | 32 | 3/16 | 5/8 | BUB-600-DC |
BUH-0625-DC |
BUH-0124-DC |
BUH-0625-DC |
Hex Design Swivot - 5/8-11 X 1 - Delrin Cone |
1 |
102903 |
CAD |
|
15/16 | 11/16 | 1 | .827 | .156 | 5/8-11 | 32 | 1/4 | 3/4 | BUB-700-DC |
BUH-0625X2-DC |
BUH-0124-DC |
BUH-0625X2-DC |
Hex Design Swivot - 5/8-11 X 2 - Delrin Cone |
1 |
103030 |
CAD |
|
15/16 | 11/16 | 2 | .827 | .156 | 5/8-11 | 32 | 1/4 | 3/4 | BUB-700-DC |
BUH-0620-DC |
BUH-0124-DC |
BUH-0620-DC |
Hex Design Swivot - 5/8-18 X 1 - Delrin Cone |
1 |
102741 |
CAD |
|
15/16 | 11/16 | 1 | .827 | .156 | 5/8-18 | 32 | 1/4 | 3/4 | BUB-700-DC |
BUH-0620X2-DC |
BUH-0124-DC |
BUH-0620X2-DC |
Hex Design Swivot - 5/8-18 X 2 - Delrin Cone |
1 |
102824 |
CAD |
|
15/16 | 11/16 | 2 | .827 | .156 | 5/8-18 | 32 | 1/4 | 3/4 | BUB-700-DC |
