Fairlane Products offers a wide variety of quick release ball lock pins that operate on a simple locking ball principle, assuring secure and safe fastening. These positive-locking pins will not release until the button on the handle is depressed. Once the button is depressed, the balls retract into the pin, allowing the pin to be removed from the hole.
The pins are available in Button. Ring, L, T, Nautical and Domed handle configurations. They are available with 4130 steel, 300 series stanless and 17-4 stainless to meet your application needs. These pins are available in both inch and metric sizes.
 |
Button Handle
Supplied with a stainless steel split ring for attaching a cable assembly. |
 |
Ring Handle
Supplied with a stainless steel split ring for attaching a cable assembly. |
 |
T-Handle
Supplied with a stainless steel split ring for attaching a cable assembly. |
 |
L-Handle
Supplied with a stainless steel split ring for attaching a cable assembly. |
 |
Nautical Handle
Designed to prevent accidental release. Machined from 303 stainless steel. |
 |
Dome Handle
The large ergonomic dome actuator button facilitates easy installation and removal. |
 |
Receptacles & End Caps
Provide a permanent and proper mating hole for quick release ball lock pins where the receiving hole is not within tolerance or is out of round. |
 |
Wire Rope Lanyards
Used to attach quick release pins to a frame to prevent the pins from being misplaced while they are not in use. |
